4-Pack, Drywall Installation Bolt/Anchor Kit by SNAPTOGGLE


 Lengths Available:
 Colors Available:
 Part Numbers this model: ZE-BB-24014

 Sales Category: TV Mounts  Approx TV Size / Weight: - , lbs Max
 VESA Type / Style: /  Vesa Specs (WxH) mm:
   Mount Holes (WxH):  Supports Curved TVs?:

The SNAPTOGGLE anchor is a heavy-duty hollow wall anchor for use in walls, ceilings, or floors of materials such as gypsum board, drywall with a wood or steel stud, concrete block, tile over drywall, wood, etc. The anchor is pre-assembled and ready for immediate use. The ratcheting strap / locking cap assembly positions the strong one-piece zincplated (or stainless) steel anchoring channel on the rear of the wall, capturing it snugly and securely between the anchoring channel and the cap.

The remaining portion of the straps on the outside of the wall are then easily and quickly snapped off by hand at the required length, flush with the surface of the wall (no extra tools required). Holding is dependent only on a metal bolt to metal channel connection. The SNAPTOGGLE anchor complies with all existing fire codes for critical applications.

We have created a convenient kit containing 4 SNAPTOGGLE anchors, and Qty (4) 4-1/2" x 1/4" Hex Bolts suitable for use with all mounts sold here at My Cable Mart.

My Cable Mart recommends 4 bolts/anchors (1 kit) for TV's 0-100lbs, and 8 bolts/anchors (2 kits) for TV's 100-150lbs. Drywall mounting TV's greater than 150 lbs using these anchors is NOT recommended.

Specifications:
  • 4 Heavy Duty "Class 5" 2-1/2" x 1/4" hex-bolts included
  • 4 Receiving Wall Anchors included
  • Suitable for DIRECT mount against drywall OR drywall and metal studs
  • Suitable for either 1/2" or 5/8" drywall
  • Solid metal channel resists vibration & shock
  • Pre-assembled and ready for immediate use
  • Pre-installs without fixture or bolt
  • Installs in a significantly smaller hole
  • Automatically adjusts to thickness of wall, ceiling, or floor
  • Uses a shorter bolt no need to carry a wing
  • New plating is 7 times more corrosion-resistant
  • Does NOT fall behind wall when bolt is removed; fixture can be removed and reinstalled as often as desired
  • Tensile Load Strength: Up to 265lbs for 1/2" drywall; Up to 356lbs for 5/8" drywall PER BOLT
  • Shear Load Strength: Up to 241lbs for 1/2" drywall; Up to 324lbs for 5/8" drywall PER BOLT
  • 1/2" drilled holes in drywall (or other material) needed per bolt
  • Suitable for walls 3/8" to 3 5/8" thick

Note: Industry safety standards recommend 1/4 of ultimate test load values shown above
