DB9-Female to RJ11/12 (6 wire) RS232 Modular Adapter Ivory

Lengths Available:
Colors Available:
Part Numbers this model:	BE-272002

Sales Category:	Adapters (All Types)	Wire Gauge (AWG):	28 AWG
Connector A:	Serial DB9 (RS-232) Female	Specification:
Connector B:	Serial DB9 (RS-232) Female	Number Ports:	N/A
Export Tariff Code (HST):	8544422000	Transfer Rate:
Feature / Style:		Images Length/Size Shown:	EA
# Positions:		Shielding:
Convert From/To:		Type:

This modular adapter has a DB9 male connector that plugs into DB9 RS232 serial port and converts it to an RJ11 or RJ12 connection.

RJ12 Pinout:

Pin1 -- White
Pin2 -- Black
Pin3 -- Red
Pin4 -- Green
Pin5 -- Yellow
Pin6 -- Blue

* Gold plated pin
* 28AWG wire
* Molded ivory color housing
* Thumb screw
