This product is recommended for use with CAT-6 cables (not included). Solid core shielded CAT cables should be used with the standard of EIA/TIA 568B. Compact size and the pair of device is housed in a metal box for better RF shielding. Each port supports HDMI or DVI inputs.

IMPORTANT: 2 shorter standard Male/Male HDMI cables also required (not included). 2 CAT6 cables required (up to 180ft of equal length, not included).

Benefits:

• The length of HDMI cables are fixed and unchangeable after it is produced to a particular
  length thus the user cannot reduce or increase its lengths. However with CAT-5e/6/7 cables
  as a cheaper alternative it gives the user the freedom to get the exact length needed
  for a professional installation.

• By using CAT-cables it's more flexible, less bulky and can easily conceal the CAT-cables.

• This HDMI over CAT-cables offers an easier, faster and a more cost effective solution.

Specifications:

• HDMI 1.3 Compliant

• Maximum Distance: 185ft. for 1080p (CAT-6a/7),

• 160ft. for 1080p (CAT-6),

• 150ft. for 1080i (CAT-5e)

• Supported Video Resolutions: 1080p, 1080p, 1080i, 720p & 480p

• Data rates: 10.2Gbps CAT-6a/7 & 5.1 Gbps CAT-5e/6

• HDMI connector type: Type A 19 pin female

• Link connector: RJ45

• Input Video Signal: 0.5-1.0 volts p-p (located at RECEIVER end of circuit)

• Input DDC Signal: 5 volts p-p (TTL)

• Dimensions: 3.25"x 1.75" x 7/8"

NOTE:Distances and picture quality may be affected by cable grade, cable quality, source, RF and electrical interferences and cable patches. Some equipment may be incompatible with using BALUM-type devices as they are unable to properly negotiate a proper HDCP "handshake" using networking cables.
